Deploying a PHP Application to Kubernetes: A GitOps Walkthrough

When you first ship a PHP backend to Kubernetes, the application code is rarely the hard part. What takes time, and iteration, is everything around it: the container, the pipeline, the secrets, the scheduler, and the runtime. This is the sequence of decisions I made deploying a Symfony app on FrankenPHP to EKS with a GitOps stack.

The service talks to external APIs (including an AI provider). That did not change the cluster shape. It did make secret paths, health probes, and a crash-on-boot smoke test non-negotiable.

The stack

  • PHP 8.3 / Symfony: application runtime
  • FrankenPHP: PHP server on top of Caddy
  • Docker: container image
  • GitHub Actions: CI/CD
  • Terraform + Terragrunt: AWS bootstrap
  • Argo CD + Helm: GitOps deploy
  • AWS EKS: cluster
  • SSM Parameter Store + External Secrets Operator: secrets into pods

1. Bootstrapping AWS with Terragrunt

Before anything runs in the cluster, the AWS side has to exist. I used Terragrunt on top of Terraform: DRY includes, remote state, environment inheritance. Not a second IaC language, a wrapper.

Remote state

State lives in S3, one key per project and environment:

remote_state {
  backend = "s3"
  config = {
    bucket       = "<your-tfstate-bucket>"
    region       = "eu-west-3"
    key          = "${local.project}/${path_relative_to_include()}/terraform.tfstate"
    use_lockfile = true
    assume_role  = { role_arn = "<deployment-role-arn>" }
  }
}

use_lockfile = true stops two applies from corrupting the same state (another engineer, or two CI jobs).

Application bootstrap module

A shared internal module owns the boring part: ECR, IAM, monitoring wiring. Each service does not copy that Terraform.

inputs = {
  deployable_to = ["staging", "production"]
  monitoring = {
    enabled      = true
    environments = ["staging", "production"]
  }
}

2. GitOps with Argo CD and Helm

Once the AWS resources exist, Argo CD watches Git and reconciles the cluster to what the repo declares.

Helm values hierarchy

deploy/argo/backend/
├── Chart.yaml              # chart
├── values.yaml             # shared defaults
├── staging/values.yaml     # staging overrides
└── production/values.yaml  # production overrides

A value in values.yaml is inherited unless an environment file overrides it. Divergence is explicit.

Resource allocation

The first profile is intentionally small:

resources:
  requests:
    cpu: 100m
    memory: 64Mi
  limits:
    cpu: 500m
    memory: 512Mi

Requests are what the scheduler guarantees. Limits are the ceiling (CPU throttle, OOM kill on memory). Start low, raise from observed usage. Do not guess production size on day one.

3. The CI/CD pipeline

Four GitHub Actions workflows cover the lifecycle:

Workflow Trigger Purpose
pull-request.yml Every PR Tests, PHPStan, build image, smoke-start the container
default.yml Push to main Build, push to ECR, deploy staging
release_on_tag.yml Git tag Deploy production
infra-as-code.yml Changes under deploy/terragrunt/ Plan or apply Terraform

Docker smoke test in CI

After building the image on a PR, start it for a few seconds and assert it is still running. A docker stop || true alone is not a test: a crash still looks green.

- name: Build Docker image (no push)
  uses: docker/build-push-action@v6
  with:
    push: false
    load: true
    tags: my-app-backend:test

- name: Test container stays up
  run: |
    docker run --rm -d --name test-container my-app-backend:test
    sleep 5
    docker inspect -f '' test-container | grep -qx true
    docker stop test-container

This catches what PHPStan will not: a missing extension, a bad entrypoint, an env var the process needs at boot.

Static analysis gate

Every PR runs PHPStan before merge. On a PHP codebase that calls external APIs, type mistakes that used to explode at runtime show up on the PR.

4. Container security hardening

The Dockerfile went through several iterations. Each change had a concrete failure behind it.

Do not let FrankenPHP terminate TLS

FrankenPHP (Caddy) defaults to port 443 and automatic certificates. Behind a Kubernetes ingress that is the wrong split:

  1. The ingress already terminates TLS
  2. Binding 443 inside the pod wants extra privilege (CAP_NET_BIND_SERVICE or root)

The fix we used is a single environment variable:

ENV SERVER_NAME=:80

SERVER_NAME is how Caddy sets the listen address. :80 is plain HTTP, no automatic certs. TLS stays on the ingress.

Drop capabilities you no longer need

FrankenPHP ships with CAP_NET_BIND_SERVICE on the binary so it can bind 443 as non-root. After moving off 443 and sitting behind the ingress, we dropped it:

RUN setcap -r /usr/local/bin/frankenphp

Least privilege: keep only what the process still needs.

Run as non-root

ARG USER=www-data

RUN \
    setcap -r /usr/local/bin/frankenphp; \
    chown -R ${USER}:${USER} /config/caddy /data/caddy /app

USER ${USER}

The process is www-data (UID 33 on Debian). chown covers:

  • /config/caddy and /data/caddy: Caddy runtime storage
  • /app: app cache and logs

Without that, the image builds, then the process dies at runtime on Permission denied.

Align UIDs between Docker and Kubernetes

Dockerfile USER www-data (UID 33) is not enough. The pod must declare the same UID:

podSecurityContext:
  runAsUser: 33
  runAsGroup: 33
  fsGroup: 33
  • runAsUser / runAsGroup: UID/GID of the process
  • fsGroup: kubelet chowns mounted volumes to this GID at start

If these drift, volume mounts fail even when the Dockerfile is correct.

5. Secrets with External Secrets Operator

API keys live in AWS SSM Parameter Store. External Secrets Operator watches ExternalSecret objects, copies values into Kubernetes Secrets, then the chart injects them as env vars.

externalSecrets:
  clusterSecretStore: <your-cluster-secret-store>
  params:
    - key: /param/my-project/staging/parameters/api_client_secret
      name: APP_API_CLIENT_SECRET
    - key: /param/my-project/staging/parameters/service_api_key
      name: APP_SERVICE_API_KEY

The failure mode I hit: Helm paths used a prefix that did not match SSM. ESO did not fail the deploy. The pod started, the env var was missing, the error showed up three layers later in application logs.

Lesson: grep the live SSM path before the first deploy. A wrong path is not a CI error.

6. CronJob for the scheduler

Background work is a Kubernetes CronJob in the same chart:

cronJobs:
  initiate-calls:
    schedule: "0 7-15/2 * * 1-5"   # every 2h, Mon-Fri, 7am-3pm
    command: "php bin/console app:my-command"
    restartPolicy: Never
    image:
      fromApp: true
      imagePullPolicy: IfNotPresent
  • fromApp: true: same image as the web deployment. Right default when bin/console and the HTTP server share the codebase.
  • imagePullPolicy: IfNotPresent: skip a pull on every tick only if the tag is immutable (digest or a unique tag). latest plus IfNotPresent will happily run a stale image.

To disable a CronJob without deleting it, set a schedule that never fires (31 February). The Helm object stays; Kubernetes does not trigger it. Restore the real schedule to turn it back on.

7. Health probes and autoscaling

Probes

readinessProbe:
  failureThreshold: 3
  periodSeconds: 10

livenessProbe:
  failureThreshold: 5
  periodSeconds: 20
  • Readiness: traffic only after the probe passes. 3 failures times 10s = 30s before the pod leaves the Service.
  • Liveness: Kubernetes restarts the pod. 5 times 20s = 100s, so cache warmup does not look like a crash loop.

Both hit a dedicated endpoint (for example /check/liveness), not /.

HPA

hpa:
  maxReplicas: 3
  minReplicas: 1
  targetCPUUtilizationPercentage: 70
  targetMemoryUtilizationPercentage: 80

At least one replica, up to three when CPU exceeds 70% or memory exceeds 80%. Staging was maxReplicas: 1. Staging should test the app, not the autoscaler.

What I would keep doing

  1. FrankenPHP behind an ingress: SERVER_NAME=:80. Default TLS on 443 fights ingress TLS.
  2. UID alignment is mandatory. Dockerfile USER, podSecurityContext, and volume fsGroup must be the same UID/GID.
  3. Verify SSM paths before deploy. A typo is silent at apply time and loud at runtime.
  4. CronJobs reuse the app image (fromApp: true) in this layout.
  5. Smoke-test the image in CI by asserting the process is still running, not by ignoring docker stop.
  6. Start probes loose, tighten later. Easier than debugging restart loops on day one.
  7. Cap staging at 1 replica. Do not rehearse HPA there.
